Overview of MERCUSYS MS106P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+
The MERCUSYS MS106P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ is a reliable unmanaged network switch designed for small businesses, offices, retail shops, surveillance systems, and home networking applications. Equipped with four IEEE 802.3af/at compliant PoE+ ports and a total PoE power budget of 67W, this switch can simultaneously transmit both power and data over a single Ethernet cable, simplifying installation while reducing infrastructure costs.
With six Fast Ethernet ports, including four PoE+ ports and two standard Ethernet ports, the MS106P provides stable network connectivity for IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices. The built-in Extend Mode supports PoE transmission distances of up to 250 meters, making it an ideal solution for long-distance surveillance deployments.
Why Choose the MERCUSYS MS106P 6-Port PoE+ Switch?
The MERCUSYS MS106P offers an affordable and efficient networking solution for powering multiple PoE devices without requiring separate power adapters. Its plug-and-play design, intelligent PoE management, and durable metal housing ensure reliable operation in demanding networking environments.
- 6 Fast Ethernet RJ45 ports.
- 4 IEEE 802.3af/at compliant PoE+ ports.
- 67W total PoE power budget.
- Up to 30W PoE output per PoE port.
- Extend Mode supports PoE transmission up to 250 meters.
- Plug-and-play installation without configuration.
- Intelligent PoE power management protects connected devices.
- Fanless silent operation.
- Desktop and wall-mount installation.
- Durable metal housing for long-term reliability.
Technical Specifications of MERCUSYS MS106P
| Brand | MERCUSYS |
|---|
| Model | MS106P |
|---|
| Product Type | Unmanaged PoE+ Desktop Switch |
|---|
| Total Ports | 6 × 10/100Mbps RJ45 Ports |
|---|
| PoE Ports | 4 × PoE+ Ports |
|---|
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
|---|
| Maximum PoE Output Per Port | 30W |
|---|
| Total PoE Budget | 67W |
|---|
| Switching Capacity | 1.2Gbps |
|---|
| Packet Forwarding Rate | 0.893Mpps |
|---|
| MAC Address Table | 2K |
|---|
| Transmission Distance | Up to 250m (Extend Mode) |
|---|
| Forwarding Mode | Store-and-Forward |
|---|
| Installation | Desktop / Wall Mount |
|---|
| Housing | Metal |
|---|
| Cooling | Fanless |
|---|
Applications of MERCUSYS MS106P
The MERCUSYS MS106P is ideal for powering and connecting multiple PoE-enabled devices while maintaining stable Fast Ethernet connectivity in professional networking environments.
- IP Surveillance Systems
- CCTV Installations
- Wireless Access Points
- VoIP Telephone Systems
- Retail Stores
- Office Networks
- Schools & Educational Institutions
- Hotels & Restaurants
- Warehouse Networks
- Small Business Networking
Benefits of Using the MERCUSYS MS106P
- Eliminates the need for separate power adapters.
- Reduces installation and cabling costs.
- Provides stable power and network connectivity.
- Supports long-distance PoE deployment up to 250 meters.
- Protects connected devices with intelligent PoE management.
- Silent fanless operation for office environments.
- Quick plug-and-play installation.
Compatibility
The MERCUSYS MS106P is compatible with IEEE 802.3af and IEEE 802.3at compliant devices, including IP cameras, wireless access points, VoIP phones, PoE splitters, and other Fast Ethernet network equipment.
Buy MERCUSYS MS106P 6-Port PoE+ Switch in Bangladesh
If you're looking for the original MERCUSYS MS106P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ in Bangladesh, this switch is an excellent solution for surveillance systems, business networks, and PoE deployments. Its 67W total PoE budget, intelligent power management, and durable design make it ideal for both commercial and professional networking applications.
Why Buy from Independent Tech BD?
- 100% Genuine MERCUSYS Products
- Competitive Price in Bangladesh
- Professional Networking Solutions
- Corporate & Project Supply
- Experienced Technical Support
- Fast Nationwide Delivery
- Reliable After-Sales Service
Frequently Asked Questions (FAQ)
How many PoE devices can the MS106P power?
The switch features four PoE+ ports capable of powering up to four IEEE 802.3af/at compatible devices within the 67W total PoE budget.
Does the switch require any configuration?
No. The MERCUSYS MS106P is an unmanaged switch with plug-and-play functionality.
What is the maximum PoE transmission distance?
Using Extend Mode, the switch supports PoE transmission up to 250 meters at 10Mbps.
Is this switch suitable for IP camera installations?
Yes. It is specifically designed for CCTV surveillance systems, IP cameras, wireless access points, and VoIP phones.
Does the switch have cooling fans?
No. It uses a fanless design for silent and maintenance-free operation.
