| Image Sensor: |
1/2.8″ STARVIS™ CMOS |
| Pixel: |
4MP |
| Max. Resolution: |
2560 (H) × 1440 (V) |
| ROM: |
4 GB |
| RAM: |
1 GB |
| Electronic Shutter Speed: |
1/1 s–1/30000 s |
| Scanning System: |
Progressive |
| Min. Illumination: |
Color: 0.005 Lux@F1.35
B/W: 0.0005 Lux@F1.35
0 Lux (IR on) |
| Illumination Distance: |
150 m (492.13 ft) |
| Illuminator On/Off Control: |
Zoom Prio/Manual/SmartIR |
| Illuminator Number: |
4 |
| Lens: |
| Focal Length: |
4.9 mm–156 mm |
| Max. Aperture: |
F1.35–F4.4 |
| Field of View: |
H: 61.6°–2.1°; V: 35.1°–1.3°; D: 68.2°–2.5° |
| Optical Zoom: |
32x |
| Focus Control: |
Auto/Semi-Auto/Manual |
| Close Focus Distance: |
1 m–1.5 m (3.28 ft–4.92 ft) |
| Iris Control: |
Auto/Manual/Fixed |
| DORI Distance: |
Detect |
Observe |
Recognize |
Identify |
| 3120 m (10236.22 ft) |
1232 m (4041.99 ft) |
624 m (2047.24 ft) |
312 m (1023.62 ft) |
| PTZ: |
| Pan/Tilt Range: |
Pan: 0°–360° endless
Tilt: –15° to +90°, auto flip 180 |
| Manual Control Speed: |
Pan: 0.1°/s–300°/s
Tilt: 0.1°/s–200°/s |
| Preset Speed: |
Pan: 400°/s
Tilt: 300°/s |
| Presets: |
300 |
| Tour: |
8 (up to 32 presets per tour) |
| Pattern: |
5 |
| Scan: |
5 |
| Power-off Memory: |
Support |
| Idle Motion: |
Preset/Tour/Pattern/Scanning |
| Protocol: |
DH-SD
Pelco-P/D (auto recognition) |
| General Intelligence: |
| Event Trigger: |
Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly. |
| IVS: |
Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly. |
| Artificial Intelligence: |
| Smart Capture: |
Support human, motor vehicle, and non-motor vehicle image capture. |
| Perimeter Protection: |
Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| Face Detection: |
Support |
| Auto Tracking: |
Support |
| SMD PLUS: |
Support |
| Video: |
| Compression: |
H.265; H.264B; H.264M; H.264H; MJPEG (Sub Stream); H.265+; H.264+ |
| Streaming Capability: |
3 streams |
| Resolution: |
4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate: |
Main stream: 4M/3M/1080P/1.3M/720P (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 720P (1–25/30 fps) |
| Bit Rate Control: |
Variable/Constant |
| Bit Rate: |
H.264: 3 Kbps–20480 Kbps
H.265: 3 Kbps–20480 Kbps |
| Day/Night: |
Auto (ICR)/Color/B/W |
| BLC: |
Support |
| WDR: |
120 dB |
| HLC: |
Support |
| White Balance: |
Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Streetlamp |
| Gain Control: |
Auto/Manual |
| Noise Reduction: |
2D/3D |
| Motion Detection: |
Support |
| Region of Interest (RoI): |
Support |
| Image Stabilization: |
Electronic |
| Defog: |
Electronic |
| Digital Zoom: |
16x |
| Flip: |
180° |
| Privacy Masking: |
Up to 24 areas, and up to 8 areas in the same view |
| S/N Ratio: |
≥ 55 dB |
| Audio: |
| Compression: |
G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 |
| Network: |
| Ethernet: |
RJ-45 (10/100Base-T) |
| Protocol: |
IPv4; IPv6; HTTP; HTTPS; 802.1x; QoS; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Interoperability: |
ONVIF Profile S&G&T; CGI |
| Streaming Method: |
Unicast/Multicast |
| User/Host: |
20 (total bandwidth 64M) |
| Storage: |
FTP; Micro SD card (256G); NAS |
| Browser: |
IE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari |
| Management Software: |
Smart PSS; DSS; DMSS; Easy4ip; IVSS |
| Mobile Phone: |
IOS, Android |
| Certification: |
| Certifications: |
CE: EN55032/EN55024/EN50130-4
FCC: Part15 Subpart B, ANSI C63.4-2014UL: UL60950-1+CAN/CSA C22.2,No.60950-1 |
| Port: |
| Audio Input: |
1 |
| Audio Output: |
1 (LINE OUT; bare wire) |
| Two-way Audio: |
Support |
| Alarm I/O: |
2/1 |
| Power: |
| Power Supply: |
AC 24V/3A ± 25% (standard)
PoE+ (802.3at) |
| Power Consumption: |
Basic: 12W
Max: 20W |
| Environment: |
| Operating Temperature: |
–40°C to +70°C (–40°F to +158°F) |
| Operating Humidity: |
≤ 95% |
| Protection: |
IP67; IK10; 6000V lightning proof; surge protection; voltage transient protection |
| Structure: |
| Dimensions: |
Φ190 mm × 332 mm (Φ7.48″ × 13.07″) |
| Net Weight: |
4.7 kg (10.36 lb) |
| Gross Weight: |
8 kg (17.64 lb) |
