V-Solution 16-Port GPON OLT | V1600G2
V1600G series GPON OLT products are 1U height 19-inch rack-mount products. The features of the OLT are small, convenient, flexible, easy to deploy, and high-performance. It is suitable for deployment in a compact room environment. The OLTs can be used for “Triple-Play”, VPN, IP Camera, Enterprise LAN, and ICT applications.
►Satisfactory standard
Meet ITU-T G984/G.988 standard
Meet China’s relevant GPON standards
►L3 OLT
Support static route RIP v1/v2、OSFP v2
►Easy to manage
Friendly EMS/Web/Telnet/CLI management
CLI command style similar to mainstream manufacturers
Support APP management
►Fully open platform
Open to any brand of ONT
►High performance cost
1U height compact design
Adopt mainstream chip scheme
SPECIFICATIONS
|
Item
|
V1600G2
|
|
Chassis
|
Rack |
1U 19-inch standard box
|
|
1000M
Uplink Port |
QTY
|
12
|
| Copper |
8*10/100/1000M auto-negotiation |
| SFP(SFP+)
(independent) |
6*SFP and 2SFP+ slots (SFP+ is 10GE port) |
|
GPON Port
|
QTY |
16 |
| Physical Interface |
SFP Slots |
| Connector Type |
Class B+/C+ |
| Max splitting ratio |
1:128 |
| Management Ports |
1*10/100BASE-T out-band port, 1*CONSOLE port |
|
PON Port Specification
|
Transmission Distance
|
20KM |
|
GPON port speed
|
Upstream 1.244G, Downstream 2.488G |
|
Wavelength
|
TX 1490nm, RX 1310nm |
|
Connector
|
SC/PC |
|
Fiber Type
|
9/125μm SMF |
|
TX Power
|
+1~+5dBm |
|
Rx Sensitivity
|
-28dBm |
|
Saturation Optical Power
|
-8dBm |
| Management Mode |
SNMP, Telnet, CLI, WEB |
| Management Function |
Fan Group Detecting;
Port Status monitoring and configuration management;
EPON management function: DBA,ONU authorization, ACL, QOS, etc.;
Online ONU configuration and management;
User management;
Alarm management.
|
| Layer2 Switch |
16K Mac address;
QOS based on port, VID, TOS and MAC address.
Access control list.
IEEE802.x flow control.
Port stability statistic and monitoring. |
| Multicast |
IGMP snooping;
256 IP Multicast Groups; |
| DHCP |
DHCP server;
DHCP relay;
DHCP snooping; |
| Layer 3Route |
Arp proxy;
Static route;
512 hardware Subnet Routes;
1024 hardware Host Routes; |
| GPON Function |
Tent dba;
Comport traffic;
In compliant with ITUT984.xstandard;
Up to 20KM transmission Distances;
Support data encryption, multi-cast, port VLAN, separation, RSTP, etc.
Specialized design for system breakdown prevention to maintain stable system;
Support dynamic distance calculation on EMS online;
Support RSTP,IGMP Proxy.
|
| Dimension(L*W*H) |
442mm*320mm*43.6mm |
| Weight |
4.5kg |
| Power Supply |
220VAC |
AC:90~264V, 47/63Hz;
Double Power Module/Hot Backup |
| Power Consumption |
85W |
| Operating Environment |
Working Temperature |
-10~+55℃ |
| Storage Temperature |
-40~+85℃ |
| Relative Humidity |
5~90%(non-conditioning) |
What is the price of the V-Solution 16-Port GPON OLT | V1600G2 in Bangladesh?
The latest price of the V-Solution 16-Port GPON OLT | V1600G2 in Bangladesh is 240,500৳. You can buy the V-Solution 16-Port GPON OLT | V1600G2 at the best price from our website or visit our showroom. Please stay connected with our What's Page or Facebook Page.
