Overview of MikroTik CSS106-5G-1S Cloud Smart Switch
The MikroTik CSS106-5G-1S Cloud Smart Switch is a compact and affordable managed Gigabit Ethernet switch designed for home users, small offices, retail stores, surveillance systems, and enterprise edge networking. Equipped with five Gigabit Ethernet ports and one Gigabit SFP port, it offers flexible copper and fiber connectivity for expanding wired networks with high-speed performance.
Powered by MikroTik SwOS, the CSS106-5G-1S provides an intuitive web-based management interface with advanced Layer 2 switching features including VLAN support, port isolation, bandwidth control, port mirroring, storm control, and traffic monitoring. Its compact desktop design, low power consumption, and wire-speed switching make it an excellent solution for reliable network connectivity.
Why Choose the MikroTik CSS106-5G-1S?
The MikroTik CSS106-5G-1S delivers professional Layer 2 switching features in a compact form factor, making it ideal for users who require efficient network management without the complexity of a full Layer 3 switch.
- 5 × Gigabit Ethernet RJ45 ports.
- 1 × Gigabit SFP fiber uplink.
- Powered by MikroTik SwOS.
- Wire-speed non-blocking switching performance.
- IEEE 802.1Q VLAN support.
- Port isolation and access control.
- Bandwidth management and traffic monitoring.
- Port mirroring for diagnostics.
- Simple browser-based configuration.
- Compact desktop design with low power consumption.
Technical Specifications
| Feature |
Specification |
| Brand |
MikroTik |
| Model |
CSS106-5G-1S |
| Product Type |
Cloud Smart Switch |
| Ethernet Ports |
5 × 10/100/1000Mbps Gigabit RJ45 |
| SFP Port |
1 × 1.25G SFP Slot |
| Switching Chip |
Atheros 8227 |
| Operating System |
MikroTik SwOS |
| Switching Capacity |
12Gbps |
| Forwarding Rate |
8.9Mpps |
| Management Interface |
Web-Based GUI |
| Supported Features |
VLAN, Port Mirroring, Bandwidth Control, Port Isolation, Storm Control |
| Power Input |
10–30V DC |
| Maximum Power Consumption |
Up to 5W |
| Installation |
Desktop |
Applications of MikroTik CSS106-5G-1S
The CSS106-5G-1S is ideal for small and medium-sized networks requiring managed Gigabit switching with fiber uplink capability.
- Home Networks
- Small Office (SOHO)
- Corporate Branch Offices
- IP CCTV Surveillance Systems
- Retail Stores
- Fiber Uplink Expansion
- Server Connectivity
- Educational Institutions
- Enterprise Edge Networks
- Small Data Centers
Benefits of Using the MikroTik CSS106-5G-1S
- High-speed Gigabit Ethernet connectivity.
- Flexible fiber uplink using SFP.
- Easy web-based management with SwOS.
- Reliable Layer 2 switching features.
- Supports network segmentation using VLANs.
- Compact design with silent operation.
- Energy-efficient and suitable for continuous use.
Compatibility
The MikroTik CSS106-5G-1S is compatible with Gigabit Ethernet routers, access points, IP cameras, network storage devices, desktop computers, servers, and standard 1.25G SFP transceivers. It integrates seamlessly into existing MikroTik and third-party Ethernet network infrastructures.
Buy MikroTik CSS106-5G-1S Cloud Smart Switch in Bangladesh
If you're looking for the original MikroTik CSS106-5G-1S Cloud Smart Switch in Bangladesh, this managed Gigabit switch offers reliable Layer 2 switching, fiber uplink capability, and professional network management features. It is an excellent choice for home users, businesses, surveillance systems, and enterprise edge deployments.
Why Buy from Independent Tech BD?
- 100% Genuine MikroTik Products
- Competitive Price in Bangladesh
- Professional MikroTik Networking Solutions
- Corporate & Project Supply
- Experienced MikroTik Technical Support
- Fast Nationwide Delivery
- Reliable After-Sales Service
Frequently Asked Questions (FAQ)
How many Ethernet ports does the CSS106-5G-1S have?
It includes five 10/100/1000Mbps Gigabit Ethernet RJ45 ports.
Does this switch include an SFP port?
Yes. It features one 1.25G SFP slot for fiber uplink connectivity.
What operating system does the switch use?
The CSS106-5G-1S runs MikroTik SwOS, offering an easy-to-use web-based management interface.
Does it support VLAN configuration?
Yes. SwOS supports IEEE 802.1Q VLANs, port isolation, bandwidth control, and several Layer 2 management features.
Is the CSS106-5G-1S suitable for CCTV and business networks?
Yes. It is widely used in IP surveillance systems, small business networks, retail environments, and fiber-connected office infrastructures.
