| General | ||
| Pan/Tilt/Rotation | Pan: 0° to 360°, tilt: 0° to 180°, rotate 0° to 360° | |
| Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | |
| Power Supply | 12 VDC ± 25%, PoE: 802.3af, Type 1 Class 3, reverse polarity protection | |
| Power Consumption | 12 VDC, 0.50 A, max. 6W PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 7 W | |
| Camera | ||
| Image Sensor | 1/3″ Progressive Scan CMOS | |
| Electronic Shutter Speed | 1/3 s to 1/100,000 s | |
| Minimum Illumination | Color: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR | |
| S/N Ratio | ≥ 52 dB | |
| IR Distance | 50 m | |
| Lens | ||
| Lens Type | 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 88° 6 mm, horizontal FOV 49°, vertical FOV 26°, diagonal FOV 57° | |
| Mount Type | M12 | |
| Max Aperture | 4 mm F2.0; 6mm F1.6 | |
| Video | ||
| Resolution | 2560 × 1440 | |
| Frame Rate | 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) | |
| Day/Night | ICR Cut | |
| BLC Mode | Yes | |
